Fume hood has comfortable handle, customized laboratory specialized waterproof socket and bottom cabinet with inside adjustable feet. It is nicely seamless with floor. Match with 260000 TFT color screen Chinese and English version microcomputer controller. Both outer and inter case have excellent acid and alkali resistance. Equipped with acid and alkali resistant 5mm HPL guide plate at back and top side of working area. High-performance guide plate make air exhaust more smooth and uniform to have an air chamber in between working area and exhaust pipeline. Guide clip is integrated with case to make it easily to dismount. Air collecting hood is made of acid and alkali resistant PP material. Bottom air inlet is rectangular and top air outlet is round. The front transparent sliding view window door is made of 5mm tempered glass, which can stop at any casual position and is in between working area and operator to protect operator. The reliable aluminum profile frame is used to fix view window to make sure operator safety. The suspended sling use synchronous structure, which has low noise, fast pulling speed and excellent balance force.
Model |
SCT-FH1200 |
SCT-FH1500 |
SCT-FH1800 |
External Dimension(W*D*H)(mm) |
1200*850*2350 |
1500*850*2350 |
1800*850*2350 |
Internal Dimension(W*D*H)(mm) |
980*640*1185 |
1280*640*1185 |
1580*640*1185 |
Power(kW) |
0.2 |
0.3 |
0.5 |
Color |
White/Blue/Green/etc(Optional) |
||
Air Velocity(m/s) |
0.5~0.8 |
||
Case Material |
Powder Coated Steel Plate/PP(Optional) |
||
Work Bench Material |
Refining Board/Epoxy Resin/Marble/Ceramic(Optional) |
||
Power Supply |
AC220/110V, single phase, 50/60Hz(Optional) |
Remark: all kinds of clean room products can be customized as actual requirement.
Both benchtop and walk-in type available, easy to operate;
Strong acid and alkali resistant performance;
Excellent safety design and optimized configuration;
Standard and customized size available.
Widely used in clean room industry, physics and chemistry laboratory, etc.
